Blade Evo Range
Sleek low-profile, modular design customised to meet the individual’s needs.
Anodised solid aluminium body for durability and aesthetics.
Standard options 2.50 (Blade I) module and 5.00 and 5.25 (Blade II) module, new custom sizes available on special request.
Ideal for high-end computer workstations.
Through wiring to allow for “daisy chain” installations via interconnect leads and splitter block.
Blade mounting under desk with NEW ZIP toolless clamps.
Modules
Power Modules:
Overload Switch
Circuit Breaker
Socket Outlets:
South African 16 Amp 3 pin
South African Dedicated
(3 versions)
South African Compact
(SANS 164-2)
South African 2 Pin
(SANS 164-6)
South African Compact Dedicated Sockets
(SANS 164-2-1) (3 Versions)
Universal 13 Amp International Socket
(Export orders only)
Schuko
(Export orders only)
Data / auxiliary modules:
Cat 5e or Cat 6
USB Combination Type C+A 60 Watt PD (Power Delivery) Charger
USB Type-C 20 Watt PD (Power Delivery) Charger
USB Type-A 18 Watt QC (Quick Charge) Charger
USB Combination Type C+A 15 Watt QC (Quick Charge) Charger
VGA
HDMI
Data Pass Thru
Options
Standard Body Colours:
Polar
Anodised silver body with white inserts.
Titanium
Anodised silver body with black inserts.
Graphite
Texture powder coated black with black inserts.
Standard Sizes available:
2.00, 2.50,3.00, 5.00 and 5.25 modules.
Custom sizes available:
1.00 - 6.00 modules.
